Description
E-Bike
Motor
Specialized 3.1 Motor, 101Nm torque, 666W power
Akku
840Wh battery
Display/Lenkerfernbedienung
All New MasterMind T3 Display System, 2.2″ high resolution color screen, fully customizeable with Specialized App
Ladegerät
Specialized 4amp charger
Rahmenset
Rahmen
All new Levo 4 M5 Alloy frame, 150mm travel,, adjustable chainstay, adjustable head tube angle, adjustable bottom bracket, internal SWAT storage 148mm spacing, 29″ front wheel/27.5″ rear wheel, fork travel up to 180mm
Sattelklemme
Alloy, 38.6mm
Gabel
Marzocchi Bomber Z1, 29″, S2-S6: 160mm, S1: 150mm, sweep adjust compression
Fahrwerk
Dämpfer
*Marzocchi Bomber Inline, EVOL LV air sleeve, rebound adjust, 210x55mm
Bremsen
Vorderradbremse
SRAM DB8 Stealth, 4-piston caliper, hydraulic disc, 220mm Centerline rotor
Hinterradbremse
SRAM DB8 Stealth, 4-piston caliper, hydraulic disc, 200mm Centerline rotor
Antrieb
Schalthebel
SRAM 70 trigger, 12-speed, single click
Schaltwerk
SRAM Eagle 70 T-Type, 12 speeds
Kassette
XS-1270, 12-speed, 10-52t
Kette
SRAM Eagle 70 T-Type Flattop Chain
Kurbelgarnitur
SRAM S1000 Crankset, ISIS Interface, Integrated Guard, 55mm Chainline, 155mm
Kettenblätter
SRAM 34t T-Type chainring, 104 BCD, steel
Laufräder
Felgen
Specialized, hookless alloy, 30mm inner width, tubeless ready
Vorderradnabe
Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h
Hinterradnabe
Alloy, sealed cartridge bearings, 12x148mm thru-axle, 32h
Speichen
DT Swiss Elemental
Vorderreifen
Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, TLR, 29×2.4″
Hinterreifen
Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, TLR, 27.5×2.4″
Laufräder und Reifen
Schläuche
Standard, Presta Valve
Cockpit
Vorbau
Alloy Trail Stem, 35mm bar bore
Lenker
Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 30mm rise, S1-S2: 780mm width, S3-S6 800mm width
Lenkergriffe
Specialized Trail Grips
Sattel
Body Geometry Bridge Saddle, steel rails
Sattelstütze
TranzX dropper, 34.9mm, S1: 100mm, S2: 125mm, S3: 150mm. S4-S5: 170mm, S6: 200mm
Zubehör
SWAT™
SWAT Internal downtube storage
Produktdetails
Konformitätszertifikat
As applicable, certified to UL 2849 (e-system) and/or UL 2271 (battery) by UL Solutions and/or SGS.
For information on lithium-ion battery standards and regulations in New York City, visit:
Gewicht
Produkt-ID
221348
Gewicht
26.08 kg (57 lb, 7.8 oz)
Gemessene Rahmengröße
S4
*Gewichte basieren auf der Produktion lackierter Rahmen, wie abgebildet. Tatsächliche Gewichte variieren je nach Farbgebung, Rahmengröße und Komponentenvariation. Spezifikationen können ohne Vorankündigung geändert werden.
